40mm 2 sheave organiser


  • Length:  111mm
  • Height:  31mm
  • Sheaves: 2 x 40mm
  • Side bearing:  Delrin balls
  • Weight:  180gr
  • Max line:  14mm
  • B:  44mm
  • Material:  Aluminium
  • Sheave Material:  Plastic
  • Fixing screws:  3 x 6mm round head
  • Sheave SWL:  800kg
  • Organiser SWL:  800kg

SKU: AT-D420

$157.05
In Stock

Groups of 2 to 6 sheaves in 4 diameters of 40, 50, 60 and 70 mm.

The 40 and 50 mm sheaves are manufactured in high-strength resin with a double side ball bearing. The 60 and 70 mm sheaves are manufactured in aluminium, hard black anodized, with a main composite fibre bearing and two side ball bearings. Double version also available, just add /D to the model number. Mounting screws, nuts and washers included.

SKU: AT-D420

  • Length:  111mm
  • Height:  31mm
  • Sheaves: 2 x 40mm
  • Side bearing:  Delrin balls
  • Weight:  180gr
  • Max line:  14mm
  • B:  44mm
  • Material:  Aluminium
  • Sheave Material:  Plastic
  • Fixing screws:  3 x 6mm round head
  • Sheave SWL:  800kg
  • Organiser SWL:  800kg
SKU AT-D420
Brand Antal
