45mm Tulip 3 sheave 12mm organiser
- Length: 185mm
- Height: 42mm
- No sheaves: 3
- Sheave (D): 45mm
- Side bearing: Delrin balls
- Weight: 0.46kg
- Max line: 12mm
- B: 52mm
- Material: Aluminium
- Sheave material: Plastic
- Fixing screws: 4 x 6mm round head
- Sheave SWL: 1000kg
- Organiser: 1800kg
SKU: AT-T530
Tulip organizer with 3 sheaves Ø 45, SWL 1000 kg
With Tulip sheaves organizers can also be made. Batteries from 2 to 6 sheaves are available, with diameters 45 and 60 mm. The 45 mm sheaves are in high resistance resin, with a “self-captive” double side ball bearing. The 60 mm sheave, with an axial bearing in composite fibre and large round bearings (self-captive) in Torlon for side loads, is in anodized and Teflon-coated aluminium and can handle very high loads.
SKU: AT-T530
- Length: 185mm
- Height: 42mm
- No sheaves: 3
- Sheave (D): 45mm
- Side bearing: Delrin balls
- Weight: 0.46kg
- Max line: 12mm
- B: 52mm
- Material: Aluminium
- Sheave material: Plastic
- Fixing screws: 4 x 6mm round head
- Sheave SWL: 1000kg
- Organiser: 1800kg
SKU | AT-T530 |
Brand | Antal |
